Product Overview

The VELscope® Vx uses natural tissue fluorescence instead of reflected light: "fluorophores" in the tissue, when excited by blue light, emit green light that may reveal cellular, structural, or metabolic changes directly related to disease processes.

Examinations require no dyes or prolonged testing procedures and can be performed in the office during routine hygiene exams, under normal lighting conditions, in about two minutes.

• Fits your workflow — complements intra- and extraoral head and neck exams with minimal set-up and nominal added appointment time
• Reveals what is hard to visualize — an imaging modality sensitive to tissue changes
• Bright, easy-to-observe visual information under typical operatory lighting
• Straightforward photo documentation for patient records and referrals
• Clinically proven for enhanced visualization of mucosal abnormalities and for helping establish surgical lesion margins
• Readily accepted by patients and staff, with strong training and clinical support
• Global market leader in tissue fluorescence visualization — over 25 million exams performed by more than 12,000 dentists in 23 countries

Indications for Use

VELscope® Vx is intended to be used by a dentist or health-care provider as an adjunct to traditional oral examination by incandescent light to enhance the visualization of oral mucosal abnormalities that may not be apparent or visible to the unassisted eye.

VELscope® Vx is further intended to be used by an oral surgeon to help identify diseased tissue around a clinically apparent lesion and thus aid in determining the appropriate margin for surgical excision.

What's Included

• VELscope® Vx wireless handheld scope (including rechargeable battery)
• Charging Cradle
• External Power Supply Brick
• AC Power Cord
• Patient Safety Glasses
• Samples of Disposables: VELcap Vx Dispenser Box (16 units), VELsheath Vx Pack (16 units)
• Documentation: VELscope® Vx Patient Brochure (50 pack), OCF Brochures (50 pack), Quick Reference Guide, Step-By-Step Examination Guide, Multi-language CD, Training & Support DVD

Caution: The VELscope® Vx System can be operated ONLY with external power brick provided with the system (Item# MENB1060A1200F03).

VELscope® Vx System Specifications

Physical

• Hand-Piece Dimensions (H x W x D): 8.6" x 2.4" x 3.4" (22 x 6 x 9 cm)
• Charging Cradle Dimensions (H x W x D): 2.5" x 4" x 7" (6 x 10 x 18 cm)
• Hand-Piece Weight: 0.9 lbs (0.41 kg)
• Charging Cradle Weight: 1.7 lb (0.76 kg)
• External Power Brick: MENB1060A1200F03, SL Power

Electrical

• Input Voltage: 100 - 240 V
• Input Frequency: 50 - 60 Hz
• Amperage: 1.5A Max @ 100VAC Input
• Output: 5A Max @ 12 VDC
• Power Cord: Hospital Grade2
• Duty Cycle: 5 min. ON; 15 min. OFF

Optical

• Nominal Output Power (400 - 460nm): ~ 1W
• Illumination Spot Diameter (@ 10 cm working distance): ~ 1.5" (4 cm)
• Minimum working distance (front face of unit to tissue): ~ 3" (8 cm)

Environmental

• Temperature (operating): 60 - 77°F (16 - 30°C)
• Temperature (non-operating): 32 - 122°F (0 - 50°C)
• Relative Humidity (operating): 20% - 80% (non-condensing)
• Relative Humidity (non-operating): 10% - 95% (non-condensing)
• Maximum Altitude (operating): 10,000 ft
• Maximum Altitude (non-operating): 35,000 ft

Awards & Accolades

VELcare Product Protection Plan

VELcare is an extended protection plan offered in addition to the 12 month factory warranty issued at the time of purchase.

Fee Schedule

• 395.00 per year on the first VELscope® unit (available on all VELscope® Vx units)
• $195.00 per year on each additional VELscope® unit (price valid based on single practice location)

One Year Coverage Includes

• Standard inbound and outbound shipping (3-5 day service) within the domestic US and Canada for all battery and light replacement parts and service*
• Free one hour training with 1 CE credit - one session offered within the active warranty period (CE eligible for one person only)
• Access to additional education material and case assessment support

Part Replacement Coverage Includes

• Battery (limit of one battery replacement per year)
• Eyepiece
• Power Supply
• Power Cord
• Charging Cradle
• Not Included: Canon camera attachment parts and accessories

Additional Unit Replacement Options

In addition to parts and service, VELcare cover also provides you with the option of replacing your VELscope® Vx unit in lieu of moving through the repair process. VELcare offers both certified refurbished units and brand new units at the following additional cost:

• $695.00 for a certified refurbished unit
• $1395.00 for a new unit

For complete program details, click here.
